Leírás
DJI Matrice 400
Legnagyobb méretű ipari drón, cserélhető payloadokkal, 6kg hsznos teher cipelése, akár 3 féle skyportos payload egyidejű csatlakoztatása, akár 59 perc repülési idő H30T kamerával
Created for: Surveying & Mapping / Public Safety / Industrial Inspections
Type: Foldable Quadcopter
Camera / Compatible gimbals / Payloads: L3, Zenmuse H30, Zenmuse H30T, Zenmuse L2 and Zenmuse P1Accessories: Zenmuse S1 (drone spotlight), Zenmuse V1 (drone speaker), Manifold 3
Dimensions (unfolded): 980×760×480 mm (L×W×H) (with landing gear)
Dimensions (folded): 490×490×480 mm (L×W×H) (with landing gear and gimbal)
Weight (incl. batteries and propellers): 9740±40 g
Batteries: One TB100
Battery capacity / Battery weight: 20254 mAh, 4720 ± 20 g
Battery charging time: TB100/TB100C Battery From 0% to 100%:220 V: 45 minutes (Fast Charging Mode); 110 minutes (Silent Mode)110 V: 70 minutes (Fast Charging Mode); 110 minutes (Silent Mode)
Max. take-off weight: 15.8 kg
Max. payload: 6 kg
Navigation : GPS + Galileo + BeiDou + GLONASS
Flight control: Custom built-in
Apps: DJI Pilot 2 (Android)DJI Flight Hub 2
Max. flight time (up to): 59 minutes with H30T, 53 minutes hover with H30T,
Max. speed (up to): 25 m/s
Max. ascent – descent speed (up to): Max Ascent Speed :10 m/s, Max Descent Speed: 8 m/s
Max. wind resistance (up to): 12 m/s
Remote controller: DJI RC Plus 2 Enterprise
Video transmission: DJI O4 Enterprise Enhanced Video Transmission System
Multi user/aircraft capability: Dual control available
Operating frequency: 902-928 MHz: < 30 dBm (FCC), < 16 dBm (MIC)2.400-2.4835 GHz: < 33 dBm (FCC), < 20 dBm (CE/SRRC/MIC)5.150-5.250 GHz: < 23 dBm (FCC/CE)5.725-5.850 GHz: < 33 dBm (FCC), < 14 dBm (CE), < 30 dBm (SRRC)
Max. distance: 40 km (FCC)20 km (CE/SRRC/MIC)
Max. Takeoff altitude (sea level): 7000 m
Operating temperature: -20° to 50° C (-4° to 122° F) (without solar radiation)
Propeller model: DJI 2510F
Obstacle Sensing Range: Omnidirectional binocular vision system (surround view provided by full-color fisheye vision sensors), Horizontal rotating LiDAR, upper LiDAR, and downward 3D infrared range sensor, Six-direction mmWave radar
